Metal Metering Box

The case is made of high-guality cold-rolled steel plate, which has good structural strength and can becustomized in appearance. lt is suitable for power distribution and metering in AC circuit systems withrated working voltage of 220-380V, frequency of 50HZ, and rated current of main bus of 250A-10A andbelow. The product meets the technical requirements and test requirements of relevant nationastandards such aslEC61439-3:2012.

E-mail

Inquiry

Details

Metal Metering Box Product Introduction

Single-phase multi-metermetal metering box

Product parameters
Model	BXD2-12
Rated working voltage	380V / 400V，220V / 230V
Frequency	50Hz
Main bus rated current	250A-10A
The fixed and short-term withstand current ofthe main bus	6kA
Enclosure protection level	IP30-operating surface IP20C
Dimensions	height 1900mm,width 750mm,depth 250mm
Shell material	cold-rolled steel plate

Single-phase multi-metermetal metering box

Product parameters
Model	BXD2-14
Rated working voltage	380V / 400V，220V / 230V
Frequency	50Hz
Main bus rated current	250A-10A
The fixed and short-term withstand current ofthe main bus	6kA
Enclosure protection level	IP30-operating surface IP20C
Dimensions	height 1900mm,width 750mm,depth 250mm
Shell material	cold-rolled steel plate
